Waste Incineration Treatment BURNING RATE : 100-150kgs per hour HICLOVER TS150

BURNING RATE : -100-150kgs per hour

MINIMUM OPERATING TEMPERATURE : 800-1000 oC ( PRIMARY COMBUSTION )

MAX OPERATING TEMPERATURE : 1000-1200 oC ( AFTER BURNER COMBUSTION )

SECONDARY BURNING CAPACITY : COMPULSORY

DENSITY INSULATION : 50 mm high

Refractory capacity : min 114mm

HEAVY DUTY REFRACTING LINING TO WITHSATND 17500C

AVEARGE BURN OUT TIME : MAXIMUM 3HRS

FUEL TYPE : FUEL OIL ( DIESEL )

FUEL CONSUMPTION IN LTRS/HR : average 14

RESIDNECY TIME IN SECONDARY CHAMBER : 2 STAGES

Items/Model

TS150(PLC)


Principle

Waste Incineration Treatment

Burn Rate

Average 100-150 kg/hour

Feed Capacity

Average 750kg/feeding

Control Mode

PLC(Programmable Logic Controller Incinerator)

Chamber Material

High Alumina Fire Brick Wall, 1750℃ Rate

Paint for outside face

800°C Rate

Combustion Chamber

1570L

Internal Dimensions

150x100x105cm

Secondary Chamber

750L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

210/230V 50/60Hz

Power

0.9Kw

Oil Consumption (Liter/hour)

Average 14(D.O)

Gas Consumption (m3/hour)

***

Temperature Monitor

Digital Display

Temperature Protection

Yes

Oil Tank

2000L

Feed Door

80x60cm

Chimney

10Meter

Chimney Type

Stainless Steel

1st. Chamber Temperature

800℃–-1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

8500kg

External Dimensions

300x160x280cm(without chimney)
