Model |
A600, crematorium manufacturers |
|||
|
Internal Dimensions |
130 x 70 x 65cm |
|||
|
Suit for Animal |
Cat – yes |
Dog – yes |
Pig – no |
Cow – no |
|
Main Product List |
Primary Combustion Chamber |
|||
|
Secondary Combustion Chamber |
||||
|
Mix-Combustion Chamber |
||||
|
Smoke Filter Chamber |
||||
|
Incinerator Control Case |
||||
|
Chimney:5.0Meters *(upgrade to Stainless Steel, free cost) |
||||
|
|
||||
|
Oil Tank (if oil fuel): 200Liters |
||||
|
Model |
A600 |
|
Picture |
|
|
Feed Capacity |
Average 30 kgs per feeding(animal) |
|
Burning Rate |
Average 15 kgs per hour(animal) |
|
Voltage |
220V |
|
Power |
0.59Kw |
|
Fuel |
Natural Gas or Diesel oil or LPG Gas |
|
Burner |
|
|
Feed Mode |
Manual Feeding |
|
Fuel consumption (Oil) |
10.0-16.0 Kgs/Hour |
|
Fuel consumption (Gas) |
10.0-15.0m3/Hour |
|
External Dimensions |
175 x 100 x 180cm (main body) |
|
Internal Dimensions |
130 x 70 x 65cm(Primary Chamber) |
|
Waste combustion chamber |
600Liters |
|
Post Combustion Chamber |
200Liters |
|
Oil Tank Capacity |
200 Liters or More(Optional) |
|
Door Opening |
50 x 60cm |
|
Chimney |
|
|
Gross Weight |
3300kgs |
|
Chamber Material |
Refractory Concrete |
|
Max. Heat Value |
160,000Kcal/Hr. |
|
Operation Technical Specifications |
|
|
Solid Chamber temperature |
800 |
|
Gas Chamber temperature |
1000 |
Chamber Anti-Rate
|
1450 |
Residency time |
2.0 Sec. |
|
Burning efficiency |
＞97% |
|
Waste Lower Calorific Power |
3000Kcal |
